PC-21 PILATUS | Item code: BH192

Views: 2289

Item code: BH192
Glow and EP

SPECIFICATION:

Wingspan: 1,962 mm (77.24 in).
Length: 2,312mm (91.02 in).
Weight: 11 kg (24.25lbs)
Wing area: 71.8 dm².
Wing loading: 153g/dm².
Wing type: Naca Airfoil.
Spinner: 115mm
Servo mount: 42mm x 21mm.
Main gear type: Electric retract gear with oleo struts (included).
Nose gear type: Electric retract gear with oleo struts (included).

Parts listing required (not included):

Radio: 07 channels minimum.
Servo: 9 standard high torque servos.
Engine: 55-65 cc gas.

– Motor: Brushless outrunner 5000 – 6500W, 180KV.

– Propeller: Suit with your engine.

Recommended motor and battery set up (not included):

Motor: Admiral GP60 8925-180KV Brushless.
Lipo cell: 12 cells 5500 – 6000mAh.
Receiver battery: 6.0V-7.4V, 2600-3200mAh (3 Packs).
ESC: 120A.

ALL BALSA – PLY WOOD CONSTRUCTION.
